Replacement ice maker, ice chute, and drain clip used for some Samsung refrigerator models.
Directly Replaces: DA97-15217D, DA97-15217B, DA97-12317A, DA97-12317B, DA97-15217A, DA97-15217E, DA97-15335A, DA97-15217A-00, DA97-15217A-00, SZAB001TA1, 4546148, AP6261445, EAP12115595, PD00037355, PS12115595, DA82-02367A, DA61-12775A, 4922147, AP6261443, EAP12115467, PD00038237, PS12115467, DA97-12540G DA97-12540A, 2606JL-04W-S39, 4545834, AP6025062, EAP11758619, PD00030367, PS11758619.
Features:
- 10 cube ice maker, anti-freezing y-clip, and auger motor kit.
- Ice maker has solid tray with electronic eye sensor.
- Improved auger motor design includes cooling fan, auger motor, and fill tube heater.
- Y-clip accessory allows for proper drainage of condensation from the cooling coils, preventing defrost ice jam.
- Includes (1) Ice Maker and Harness Assembly, (1) Auger motor assembly with fan and 12 wire harness, (1) Cooling Loop Retainer, (2) Y-Clips.
APNDA97-15217D Ice Maker Specifications:
- Color: White.
- Material: Plastic Housing.
- Electrical Specs: 120VAC, 60Hz, 141W.
- Overall Dimensions: 14"L x 4"W x 5-1/8"H.
- Additional Dimensions: Harness and plug measure 9-3/4"L.
APNDA97-12540G Auger Motor Specifications:
- Color: White.
- Material: Plastic / Metal.
- Electrical Specs: Rated 115V, 60Hz; Heater - 12VDC, 2.3W; Fan Motor - 12VDC, 0.10A.
- Motor Assembly Dimensions: 8"L x 4-3/8"W x 6-3/8"H.
- Additional Dimensions: Wire harness extends 14-1/2" from motor.
APNDA82-02367A Y-Clip Specifications:
- Color: White / Translucent.
- Material: Plastic / Metal.
- Finish: Matte.
- Retainer Dimensions: 2-1/4"L x 1-1/4"W x 1/2"H.
- Additional Dimensions: Y-clips are 1-1/16"L.
